首要手艺参数：Main Technical Parameters

机型 Model	CLFQ-W1300	CLFQ-W1600
质料宽度 MAX.Width of raw material	1300mm	1600mm
放卷直径 Max.parent Web Diameter	Φ1200mm	Φ1200mm
收卷直径 Max.Rewinding Diameter	Φ1000mm	Φ1000mm
机器速率 Max.Machine Speed	10-300m/min	10-300m/min
资料厚度 Thickness of raw material	0.008-0.2mm	0.008-0.2mm
总功率 Total Power	19KW	23KW
分量 Machine Weight	4300kg	4800kg
形状尺寸 Overall Dimensions	2700×2900×1800mm	3000×2900×1800mm
分切宽度 Min.Slitting Width	50mm

可，并按照物质post请求 定做紫装。

Can be made according to th🧸e product requires special equipment.

终产物声明函合适规模较超声波焊接机混用于常见大形板料的模切，如30g/m2-300g/m2人造革纸、白彩色卡纸、淋膜纸、铝箔纸、PVC金属、锡纸等板料的模切、复卷等。器能及特性1. 该选果机尊重异步交流伺服电机汽车电器工程专业(矢量素材汽车电器工程专业)控制、主动性锥度拉力，里边卷取体例。电脑主机尊重定频控速，追求快速增长两类衡电脑运行。2. 主动权计米、警告功较。收卷得到A、B气胀轴构造，卸装控制便捷性。3. 放卷容忍光电科技主动地纠偏批阅体系中，使不发则质料能一般的分切机。4. 圆刀纵切废边自主减排搭配。5. 汽压式主动的送料，配气胀轴。6.导轨式相互开料组装。

product manual

Scope of application

This machine is suitable for the s𝄹litting of various super-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC pla🍌stic, tin foil and other coils.

Performance and characteristics

1. The machine adopts asynchronousꦚ servo motor (vector motor) control, automatic taper tension and center winding method. The main engine adopts frequency conversion speed regulation to maintain balanced operation during acceleration.

2. Automatic meteringඣ and alarm function. The winding adopts the A and B air expansion shaft structure, and the unloading operation is convenient.

3. Unwinding adopts photoelectric automatic correction correction system to make irregular mat𝕴erials cut normally.

4. The circular knife cuts the waste side automatic discharge🌼 device.

5. Hydraulic auto⛎matic feeding, with air expansion shaft.

6. Rail type automatic cutting device.
