核心厨艺技术参数 Main Technical Parameters

机型 Model	CLFJ-B1000	CLFJ- B1300	CLFJ-B1600
卷材宽度 MAX.Parent Web Width	1000mm	1300mm	1500mm
放卷直径 Max.parent Web Diameter	Φ800mm	Φ800mm	Φ800mm
收卷直径 Max.Rewinding Diameter	Φ300mm	Φ300mm	Φ300mm
速率 Max.Machine Speed	10-150m/min	10-150m/min	10-150m/min
定长精度 Fixed length accuracy	±5mm	±5mm	±5mm
总功率 Total Power	3KW	3.5KW	4.5KW
分量 Machine Weight	1000kg	1200kg	1500kg
形状尺寸 Overall Dimensions 任务电压 Working Voltage	2600×2000×1600mm      二相220V50HZ	2600×2200×1600mm      二相(xiang)220V50HZ	2600×2500×1600mm      三(san)相(xiang)380V50HZ
纸芯规格 Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)

合吃面积终端服务器关键性用作几大类纸制品，纸塑pp类，膜类等装潢相关质料和包装机相关质料的复卷修边分切机。

机器及特性 1.远程服务器进行系列伺服定长上料功能，在公路运营中严格要求自己高可靠性强，精密度。2.PLC触屏屏主動计米，米数主動因素。3.圆刀/直刀纵切废边自觉排放标准转配。4.气动平衡式主动性送料，收、放护符配气胀轴。5.活跃掐断、智能停车是舒适确定，预送预测出收法杖再长期收料等功能主治。

Scope of application

This machine is mainly used for re-winding and trimming of various papers, paper-plas𒐪tic composites, film and other decorative materials as well as packaging materials.

Performance and characteristics

1. This machine adopts servo 𒀰fixed length feeding to maintain high precision during high speed operation.

2. PLC🅠 touch screen automatically counts meters, meters are automatically set.

3. Round knife / straight knife slitting autom💃atic waste discharge device.

4. Pneumatic automatic feeding, recei💧ving and discharging r🐠eels with air expansion shaft.

5. Automatic cutting, free parking time setting, pre-feeding tജo rewind and continue to receive materials.
