共用规模较这个机器核心中用分类纸材，纸塑pp类，膜类等装潢素材和外包装素材的复卷。

卡能及独特的 1.该机采纳伺服控制器定长送料机，在高启动中始终如一高精密度较。2.PLC触屏屏自主的计米，米数自主的设计。3.气动平衡式被动放料，收、放魔石配气胀轴。4.自觉中断、驻车之前任何设置，预送猜测收魔石再一直收料等好处。Scope of applicationScope of applicationThis machine is mainly used for re-winding of various paper, paper-plastic composite, film and other decorative materials and packaging materials.

Performance and characteristics1. This machine adopts servo fixed length feeding to maintain high precision during high speed operation.2. PLC touch screen automatically counts meters, meters are automatically set.3. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft.4. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive materials.

首要手艺参数 Main Technical Parameters

外形 Model		CLFJ-B800	CLFJ- B1000	CLFJ-B1300
卷材防水大小 MAX.Parent Web Width		800mm	1000mm	1300mm
放卷直经 Max.parent Web Diameter		Φ600mm	Φ600mm	Φ600mm
收卷直(zhi)徑 Max.Rewinding Diameter		Φ300mm	Φ300mm	Φ300mm
强度(du) Max.Machine Speed		10-180m/min	10-180m/min	10-180m/min
定(ding)长的(de)精密度Fixed length accuracy		±5mm	±5mm	±5mm
总工作功率 Total Power		2.3KW	3KW	4.5KW
参(can)量 Machine Weight		1000kg	1200kg	1500kg
形(xing)壮厚度 Overall Dimensions 工作电流 Working Voltage		2600×2000×1600mm 二相220V50HZ	2600×2200×1600mm 二(er)相220V50HZ	2600×2500×1600mm 三相380V50HZ
纸芯规(gui)格为Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)
